1,000kg IcePort

The Ziegra ZBE 1.000-IcePort makes up to 1,000kg of flake ice in one of three sizes and stores  ice ready for use in your choice of ice cart below the machine. The machine is mounted above the cart on an elevated frame. Does not include the BR ice cart(s) shown, which should be purchased separately.

ZBE 1.000 main features

  • Ice level control system included as standard
  • Granular flake ice made at optimum temperature of -0.5°C.
  • Three sizes of ice flake available: micro, midi or macro.
  • Hygienic design with a sealed water system
  • External water filtration system supplied as standard.
  • Designed for continuous operation 24/7
  • Powder coated frame and panels (stainless optional)
  • No moving parts in refrigeration circuit lowers risk of gas leaks

IcePort main features

  • Compatible with BR80 / BR90  ice carts, or other carts of a similar size.
  • Improved protection against external contamination e.g. touching the ice, airbourne dust, spillage etc.
  • Protects from melt loss, warm air is inhibited from circulating directly above the ice.
  • The straight to cart design avoids the need to shovel the ice from a static bin
  • Mobile ice storage, IcePort can be positioned away from where the ice is used.
  • Easy to install, maintain and clean.

Enquire about this Machine now

Model

ZBE 1.000-IcePort
Standard

ZBE 1.000-IcePort
Tropical
1,000kg / 24h nominal capacity*

at 20°C air and 15°C water

at 35°C air and 25°C water
Dimensions (W x D x H)

1200 x 900 x 1950mm
Weight

285kg

295kg
Cabinet

stainless steel 1.4301
Ice discharge

Type R
Electricity
Power consumption
current consumption
Provided by customer
electric supply
fuse, slow-blow
cable cross section, Cu

3.3kW
7.5A

3/N/PE ~ 400V 50Hz
25A
2.5mm2

4.3kW
8.5A

3/N/PE ~ 400V 50Hz
20A
2.5mm2
Water
supply / drain
Provided by customer
pressure
quality
pH-value
hardness
temperature

3/4” BSP / 14mm O/D hose

2-5 bar
drinking water
7.2 – 9.5 pH
6 – 14 °dH / 100 – 250 mg CaCO3/l
5°C – 30°C
Ambient temperature

5°C to 42°C

5°C to 45°C
Condenser
airflow
heat emission

air cooled
2,900 m3 / h
7.5 kW

air cooled
3,000 m3 / h
10.3 kW
Refrigerant R452a
ODP
GWP
CO² tonnes equivalent
F-Gas leak check

2.2kg
0
2140
4.708
Not required

2.8kg
0
2140
5.992
Annual
Compressor

refrigeration capacity
evaporation temperature
condensation temperature

Fully hermetic

5.0kW
-22°C
33°C

Fully hermetic

5.6kW
-21°C
45°C
Noise level

60dBA (3m)
Shipping dimensions: W x D x H

0.89 x 0.82 x 1.19m
Shipping weights

195kg

205kg
*according to site conditions. Air temperature, water temperature, water chemistry, air contamination and installation parameters can all effect ice output.

All product, product specifications and data are subject to change without notice


A: Ice machine
B: IcePort
C: Electrical connection
D:  Water inlet: 3/4″
E: Overflow ø 14mm
F: Floor drain (by customer)
G: Ice cart BR80 (option)

The ZBE 1.000-IcePort ice machine will be delivered according to CE standards and ready for connection to water power and drain.

Includes as standard:

  • Condensation control
  • Phase sequence relay
  • Motor protection for the compressor
  • Overload cut-out / thermal switch for all motors and compressor
  • High pressure pressostat
  • Water level monitoring
  • Ice discharge hose / tube depending on ice discharge option chosen
  • Level control by light scanner when cart is full
  • Flexible hose water for water supply 2m
  • Water drain hose 2m
  • PE ice scoop
  • IcePort frame
  • Ziegra triple external 3 stage water filtration unit

Configuration Options
Drain Pump

Pumps the drain water into the site drain if it is too high or far away for gravity drainage. Supplied with a 2 metre flex, it can be directly wired into a fused spur or a plug fitted (not supplied) and plugged into a standard 3 pin socket. Mount on the floor underneath the machine. Not suitable for dusty environments.
Condenser options

Water cooled instead of air-cooled:  where air-cooling is not possible.Useful in applications where the machine must be installed into an area with poor ventilation where a remote aircooled condenser is not possible.

Remote condenser option: The condenser supplied separately to the machine for remote mounting, typically outside, when the machine is to be located in areas that poorly ventilated or have airbourne contamination such as flour dust. Available as standard for indoor mounting, weatherproof for outside mounting and cu/cu saltwater resistant for mounting in areas close to the sea.

Low noise condenser: Only for remote installation. Use when the condenser will be going in an area sensitive to noise, such as residential.
Frostguard: The machine equipped to deal with intermittent temperatures below 5°C, only available in conjunction with remote condenser option above.

CoolNat Ice maker only

Swap ice machine for an ice maker only for connection to your central CO2 refrigeration system.

Additional Hygiene Options
Hygiene +: Automatic cleaning, disinfection and flushing inc. drain

Auto hygienic cleaning of system with detergent, disinfectant and water. Details on request.
Hygiene +: UV sterilization

sterilization of the incoming water supply by mean of UV filter, all incoming water is passed through a powerful UV field on its way into the machine which kill almost all biohazards in the water supply. Slows down proliferation of water-borne bacteria inside the machine during operation.

Sanitiser solution: 5litre tub part # ZUK9700044
Ziegra ice machine sanitiser is an anti-bacterial product designed for both regular preventative use and intensive cleaning operations.

Spare filter cartridges: Set of replacement cartridges for the Ziegra triple kit that comes as standard with this machine, The fine and coarse cartridges require change every 6 months, the anti-scale when it runs low. Order part ZUK9700031KIT.

Set consists of :

1 x ZUK9700033 – Coarse filter

1 x ZUK9700032 – Anti-scale filter

1 x ZUK9700031 – Fine filter.

Ancillary Items
BR 80 insulated ice cart

80kg capacity insulated ice cart, moulded from food safe polymer for maximum hygiene. With removeable lid. For customers without existing carts.
7 day timer

Allows programming of the machine to make ice at specific times of the day or night.
GRP plantroom: A standalone GRP plantroom to protect the ice machine from the elements and thieves when the machine must be mounted outdoors. Arrives fully assembled, needs only a suitable base to bolt it down to. Only available with remote condener option above.
